LRT (Lift-Rotate-Transfer) Patient Transfer System

The LRT Patient Transfer System is an advanced mobility solution designed to simplify and enhance patient handling in clinical, care home, and home-care environments. Engineered for safe and efficient operation, it allows caregivers to lift, rotate, and transfer patients with minimal physical effort, significantly reducing the risk of strain or injury.

This innovative system features a strong yet lightweight frame, smooth 360° rotation, and stable transfer support, making it ideal for patients with limited mobility or those recovering from surgery, injury, or illness. Its ergonomic design promotes comfort and dignity for the patient, while its intuitive controls ensure ease of use for carers of all experience levels.

Built from high-quality, easy-to-clean materials, the LRT is durable enough for everyday use in demanding healthcare settings. Its compact footprint makes it suitable for small spaces, and its versatile design accommodates a wide range of patient needs, including mobility assistance, rehabilitation exercises, and long-term care.

Whether in a hospital ward, nursing home, or private residence, the LRT Patient Transfer System delivers consistent, safe, and reliable performance—enhancing patient wellbeing and caregiver efficiency.

Features

Lifting Capabilities: A 440lbs/300lbs weight capacity options, reaching flat or cathedral ceilings up to 14’, or a customizable height up to 16’.

Reach Capability: Boasting a 360-degree rotating  articulating arm, it provides an unrivaled 6’ arm/12' range of motion with a lifting capacity of 300lbs, and  5' arm/10' range and 4’ arm/8’ range, both with a  lifting capacity handling of 440lbs.

Multipurpose Attachments: The LRT provides versatile mounting choices, making it suitable for a wide range of installations, such as in mobile homes, on cathedral ceilings, between ceiling and floor joists, and on walls.

Lifting Height: Various base options facilitate lifting heights exceeding 9’, accommodating higher elevated lifting surfaces such as beds.  Attaching to ceilings up to 16’

Vertical Clearance: Featuring a 5-position height-adjustable arm and various base options, providing maximum flexible with vertical clearance.

Rotation Stops: The system features adjustable "Rotation Stops" that can be set to limit the maximum movement right and left of the arm. Users have the flexibility to configure each side differently based on their specific requirements. For example, you can set the rotation stops to prevent the arm on the right from reaching the wall, while on the left side, you can restrict it from extending over a nightstand. This suits various needs and spatial constraints.

Swivel Eyelet: The swiveling eyelet has a large opening of 1.16”. Freely swivels to prevent the lift strap from twisting and binding.

VERSATILE PLACEMENT OPTIONS: The LRT offers versatile placement options and easy    mobility. You can position multiple LRTs throughout your home, thanks to its portable motor, which facilitates seamless transfers from one LRT to another, ensuring   accessibility to every room in your living space.

Transfers Through Doorways: The LTR is not only designed for within room transfers, but it can also assist transfers through narrow doorways to bathrooms and bedrooms.

LRT Install Assist: While some individuals may possess the skills to independently install the LRT, not every contractor/ installer can accomplish this task solo. Fortunately, the installation process can be made remarkably straightforward with the assistance of the "LRT Install Assist" (LIA). The LIA streamlines the mounting of the mast and arm, ensuring a hassle-free installation experience.

Portable Motors: The LRT comes with three optional motor choices. It designed to work with multiple manufacturers portable motors. Regardless of the motor chosen, do not exceed the LRT’s weight capacity of 300lbs. or 440lbs.

Specifications

Weight Capacity:  440 lbs.
Weight: 108 lbs
Arm Length:  5' Arm (10' range), 4' Arm (8' range)
Height:  8' to 14' ceilings  (above 14' ceiling height please call for custom options)
Mounting: Mounted floor-to-ceiling or floor-to-wall
